Giant Revolt 1

£1,499.00

Available from warehouse
Dispatched between 20th Jan and 22nd Jan.
Part Number:

9080014118

GTIN:

4711291239593

Ride roads, gravel or dirt with this versatile aluminum all-rounder. A composite fork gives it a smooth ride, and a flip chip lets you adjust wheelbase and tire clearance.

Key Performance Factors

Confident handling

Frame is designed with endurance positioning and shorter chainstays for precise handling, agility and control. A longer reach, shorter stem and lower bottom bracket drop improves stability on rugged terrain.

Tuned compliance

Dropped seatstays with thin tubing absorb road shocks and vibrations. The D-Fuse handlebar and seatpost work as a system to add compliance without sacrificing stiffness while cornering, sprinting or climbing.

Adaptable to the terrain

A flip chip on the rear dropout adjusts the wheelbase: short for quicker handling and acceleration, or long for improved stability at speed. The long setting allows for larger diameter tires up to 53mm. You can choose the included D-Fuse seatpost for maximum compliance, or switch to a 30.9mm round or dropper post.

  • Sizes S, M, M/L, L, XL
  • Colours Alpine Green
  • Frame ALUXX-grade aluminum, 12x142mm thru-axle, disc, flip chip dropout
  • Fork Advanced-grade composite, full-composite OverDrive steerer, 12mm thru-axle, disc
  • Handlebar Giant Contact XR D-Fuse, 31.8mm XS:42cm, S:42cm, M:44cm, M/L:44cm, L:46cm, XL:46cm
  • Stem Giant Contact, 8-degree XS:50mm, S:60mm, M:70mm, M/L:80mm, L:80mm, XL:90mm
  • Seatpost Giant D-Fuse, alloy, 14mm offset
  • Saddle Giant Grit
  • Pedals PEDALS NOT SUPPLIED
  • Shifters Shimano CUES U6030, 2x10
  • Front Derailleur Shimano CUES U6030
  • Rear Derailleur Shimano CUES U6020
  • Brakes Shimano CUES U6030 hydraulic, Giant MPH rotors [F]160mm, [R]160mm
  • Brake Levers Shimano CUES U6030 hydraulic
  • Cassette Shimano CS-LG300, 11x39
  • Chain KMC X11
  • Crankset Shimano FC-U6030-2, 32/46 XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
  • Bottom Bracket Shimano, threaded
  • Rims Giant S-X2, alloy
  • Hubs Giant alloy, 12mm thru-axle
  • Spokes stainless
  • Tyres Giant CrossCut AT 2, 700x38c, tubeless
  • Extras tubeless prepared
  • Max Tyre Clearance 53mm max tyre size in "long" flip chip position, 45mm max tyre size in "short" flip chip position with 1x drivetrains. Max tyre size with a 2x drivetrain is 45mm in the long position.
Colours Alpine Green
Sizes Large, Medium, Medium - Large, Small, X-Large
Brand Giant
Model Year 2026
Barcodes 4711291239555, 4711291239562, 4711291239579, 4711291239586, 4711291239593
SKUs / Part Numbers 9080014114, 9080014115, 9080014116, 9080014117, 9080014118

Please note: Manufacturers can sometimes change the specification of the products from time to time.
